All GEAR Side Drive in Oil Bath Gear Box - NO Belts, NO Chains Only Excellent Results & Excellent Power Transfer!
Rock Crushing Capable
Valentini L1500 Recovering Wasteland In One, Beautiful & Efficient Pass!
'L' SERIES FORESTRY TILLERS FOR 80-170HP TRACTORS
As with ALL Valentini Forestry Tillers, the 'L' Series has been Providing Superior 'Single Pass' Results in All Applications: Land Clearing & Reclamation, Agriculture (Row Cropping, Produce Rows, Pastures, Seed Bed Preparation, Horticultural Benches & Rows, Vineyards, Orchards, Groves, etc.), as well as Rough or Finish Grading in Pre & Post Construction Applications. From Stump Grinding, Soil Shredding, Soil Stabilization and even Stone Crushing, Valentini Forestry Tillers Have Been CRUSHING IT for Decades!!! In the Sample Videos Below, You'll See Evidence of the Superior Single Pass Performance in the Absolute Worst & Most Demanding Conditions, Crushing Rock! Compared to Rock Crushing the Largest, Hardest Tree Stumps, and any other Timber or Organic Matter, even the Driest & Hardest Clay Soils & Shale, are a Piece of Cake!
STANDARD FEATURES:
Category 2, 3-Point Hitch.
Cam Clutch Protected PTO Shaft!
It Doesn't Get Any Better Than a Cam Clutch: The Most Efficient & Reliable Driveline Protection Available!
No Maintenance, Automatic Clearing & Resetting After Locked Rotor Conditions.
Dual Transmission Models have Slip Clutch Protected Side Drive Shafts.
Forestry Tiller's 'Diminishing Chamber' is Comprised of the Following:
Front Shear Bar Provides First Mechanical Contact for Reducing Fragments.
Rear Hardox Grid Provides Secondary Contact for Further Fragmentary Reduction.
Hydraulically Controlled Rear Containment Door Controls the Duration That Fragments Remain in the Chamber:
Rear Containment Door Can be Opened or Closed On-The-Fly During Operation!
Containment Door Constructed for Extreme Service Duty & Wear Resistance.
Forestry Tiller's Body Internal Hardox Lining is Replaceable.
Extreme Service Duty Rotor is Shock & Wear Resistant.
19" Rotor Working Diameter, Tip to Tip.
Central & Side Gear Drives in Oil Bath Gearboxes:
Single Transmission Units Have Oil Bath Bearing Enclosures for Non-Drive Side.
Dual Transmission Units have Oil Bath Gearboxes on Both Sides.
Multi-Speed Central Gearbox ‘Option’ Available For Faster Rotor Speed:
Two Speeds @ 540 & Two Speeds @1000RPM.
Faster Rotor Speed Recommended for the Most Demanding Rock Applications.
Faster Rotor Speed Also Recommended for Max Reduction of Woody Material w/No 40 Teeth!
Unique & Patented Labyrinth Seals Ensure Bearings are Protected from Dirt!
Wear Plates/Skid Shoes on Both Sides of Crusher.
Valentini ‘VN1000’ Forestry Tiller w/Offset to Accommodate Driving & Mulching Thru Rows as Shown!
For Mulching Wood Debris, Stump Grinding & Stone Crushing in the Most Demanding Conditions, Including Sandy, Abrasive Soils, Leaving Behind a Beautiful Seed Bed! Multi-Speed Gearbox For Superior Performance in Universal Applications!
Valentini ‘RA2500’ Forestry Tiller Deep Mulching Stumps & Roots After Clear Cutting a Large Field of Mature Mixed Trees!
Valentini Double Transmission L2300DT With Hydraulically Operated Rear Gate For ‘On-The-Fly’ Control of Opening/Closing to Control Fragment Size & Ground Speeds!
Beautifully Reclaimed Vineyard Aisleways Making Access Convenient & Safe for Personnel & Equipment!
Valentini L2300DT With Hydraulically Operated Rear Gate For ‘On-The-Fly’ Control of Diminishing Chamber Gate & Also Hydraulically Controlled Rear Packer Roller For Efficient & Convenient ‘On-The-Fly’ Working Depth Adjustment!
‘L’ Series Forestry Tiller with Road Grader Blade Dressing a Gravel Road in One Efficient Pass!
'L' SERIES FORESTRY TILLER SPECIFICATIONS
MODEL
L1000
L1300
L1500
L1800DT
L2000DT
L2300DT
Tractor Horsepower
80-110HP
80-110HP
90-110HP
110-170HP
110-170HP
110-170HP
PTO Speed
540 RPM
540 RPM
540 RPM
1000 RPM
1000 RPM
1000 RPM
Rotor Speed
323 RPM
328 RPM
Working Width
42"
52"
62"
72"
82"
92"
Overall Width
51"
61"
71"
82"
92"
101"
Quantity of Teeth
103
131
159
186
214
241
Working Depth on Non-Passive Surfaces
(e.g. Hard & Dry Heavy Soils, etc.)
3"
Working Depth on Passive Surfaces
(e.g. Dirt, Gravel, Sod, etc.)
7"
Weight
2,200 lbs.
2,618 lbs.
2,910 lbs.
3,630 lbs.
3,960 lbs.
4,290 lbs.
Weights are Less Pallets, Crates, PTO Shaft & Rollers.
(DT) Denotes Double Transmission
'L' SERIES FORESTRY TILLER SPECIFICATIONS
MODEL
L1000
L1300
L1500
L1800DT
L2000DT
L2300DT
Tractor Horsepower
80-110HP
80-110HP
90-110HP
110-170HP
110-170HP
110-170HP
PTO Speed
540 RPM
540 RPM
540 RPM
1000 RPM
1000 RPM
1000 RPM
Rotor Speed
323 RPM
328 RPM
Working Width
42"
52"
62"
72"
82"
92"
Overall Width
51"
61"
71"
82"
92"
101"
Quantity of Teeth
103
131
159
186
214
241
Working Depth on Non-Passive Surfaces
(e.g. Hard & Dry Heavy Soils, etc.)
3"
Working Depth on Passive Surfaces
(e.g. Dirt, Gravel, Sod, etc.)
7"
Weight
2,200 lbs.
2,618 lbs.
2,910 lbs.
3,630 lbs.
3,960 lbs.
4,290 lbs.
Weights are Less Pallets, Crates, PTO Shaft & Rollers.
(DT) Denotes Double Transmission
Specifications & Designs Are Subject to Change Without Notice
