All GEAR Side Drive in Oil Bath Gear Box - NO Belts, NO Chains Only Excellent Results & Excellent Power Transfer!
Rock Crushing Capable
Valentini ‘AA” Series Efficiently Recovering Large Area of Wasteland (Next to Pivot Irrigated Fields) Now Available For Agricultural Use…All In One Beautiful & Efficient Pass!
'AA' SERIES FORESTRY TILLERS FOR 200-450HP TRACTORS
As with ALL Valentini Forestry Tillers, the 'AA' Series has been Providing Superior 'Single Pass' Results in All Applications: Land Clearing & Reclamation, Agriculture (Row Cropping, Produce Rows, Pastures, Seed Bed Preparation, Horticultural Benches & Rows, Vineyards, Orchards, Groves, etc.), as well as Rough or Finish Grading in Pre & Post Construction Applications. From Stump Grinding, Soil Shredding, Soil Stabilization and even Stone Crushing, Valentini Forestry Tillers Have Been CRUSHING IT for Decades!!! In the Sample Videos Below, You'll See Evidence of the Superior Single Pass Performance in the Absolute Worst & Most Demanding Conditions, Crushing Rock! Compared to Rock Crushing the Largest, Hardest Tree Stumps, and any other Timber or Organic Matter, even the Driest & Hardest Clay Soils & Shale, are a Piece of Cake!
STANDARD FEATURES:
Category 3, 3-Point Hitch.
Single Speed Unit, 1000RPM.
Cam Clutch Protected Main PTO Shaft!
It Doesn't Get Any Better Than a Cam Clutch: The Most Efficient & Reliable Driveline Protection Available!
No Maintenance, Automatic Clearing & Resetting After Locked Rotor Conditions.
All Models are Dual Transmission Units with Slip Clutch Protected Side Drive Shafts.
Forestry Tiller's 'Diminishing Chamber' is Comprised of the Following:
Front Shear Bar Provides First Mechanical Contact for Reducing Fragments.
Rear Hardox Grid Provides Secondary Contact for Further Fragmentary Reduction.
Hydraulically Controlled Rear Containment Door Controls the Duration That Fragments Remain in the Chamber:
Rear Containment Door Can be Opened or Closed On-The-Fly During Operation!
Containment Door Constructed for Extreme Service Duty & Wear Resistance.
Forestry Tiller's Body Internal Hardox Lining is Replaceable.
Hydraulically Controlled Front Opening Gate & Deflectors for Infinite Adjustment.
Keep Front Gate Closed for Max Deflector use, or Open For Max Working Depth.
Extreme Service Duty Rotor is Shock & Wear Resistant.
Rotor Working Diameter, Tip to Tip:
31.5” ‘L’ Series.
36” ‘N’ Series.
45.5” ‘M’ Series.
Central & Side Gear Drives in Oil Bath Gearboxes.
Single Transmission Units Have Oil Bath Bearing Enclosures for Non-Drive Side.
Dual Transmission Units have Oil Bath Gearboxes on Both Sides.
Unique & Patented Labyrinth Seals Ensure Bearings are Protected from Dirt!
Hydraulically Adjusted Rear Skid Shoes.
The Valentini ‘AA’ Series Offers the Most Protruding Rotors for the Deepest Grinding Requirements. These Deep & Protruding Rotors Also Produce the Unparalled Efficiencies of Reduced Resistance, and Reduced Power Consumption which results in Reduced Fuel Consumption, and Better Ground Speeds, by Keeping the Machine Out of The Ground! Valentini’s Rotors are Highly Populated with ‘Chevron Patterned’ Carbide Teeth That Work With the Integral Reducing Grid To Achieve the Smallest Timber & Rock Fragments.
Valentini ‘AA” Series Grinding in Thick Shale!
Valentini ‘AA” Series Efficiently Recovering Large Area of Wasteland (Next to Pivot Irrigated Fields) Now Available For Agricultural Use…All In One Beautiful & Efficient Pass!
Valentini ‘VN1000’ Forestry Tiller w/Offset to Accommodate Driving & Mulching Thru Rows as Shown!
Valentini ‘RA2500’ Forestry Tiller Deep Mulching Stumps & Roots After Clear Cutting a Large Field of Mature Mixed Trees!
For Mulching Wood Debris, Stump Grinding & Stone Crushing in the Most Demanding Conditions, Including Sandy, Abrasive Soils, Leaving Behind a Beautiful Seed Bed!
For Mulching Wood Debris, Stump Grinding & Stone Crushing in the Most Demanding Conditions, Including Sandy, Abrasive Soils, Leaving Behind a Beautiful Seed Bed!
Top View Valentini 'AA2500' Series!
'AA' SERIES FORESTRY TILLER SPECIFICATIONS
MODEL
AA1800DT
AA2000DT
AA2300DT
AA2500DT
AA2800DT
AA3000DT
L
N
M
L
N
M
L
N
M
L
N
L
N
L
N
Tractor Horsepower
200-450HP
220-450HP
320-450HP
220-450HP
240-450HP
340-450HP
240-450HP
280-450HP
360-450HP
280-450HP
320-450HP
300-450HP
340-450HP
320-450HP
360-450HP
Rotor Diameter
31.5"
36"
45.5"
31.5"
36"
45.5"
31.5"
36"
45.5"
31.5"
36"
31.5"
36"
31.5"
36"
Working Width
5'-9"
6'-7"
7'-5"
8'-3"
9'-1"
9'-11"
Overall Width
7'-3"
8'-1"
8'-11"
9'-9"
10'-7"
11'-5"
Quantity of Teeth
152
170
228
170
185
265
198
220
302
214
238
232
256
250
274
Side Drive Gears (Qty)
4
6
4
6
4
6
4
4
4
Working Depth on Passive Surfaces*
(e.g. Dirt, Gravel, Sod, etc.)
16"
20"
28"
16"
20"
28"
16"
20"
28"
16"
20"
16"
20"
16"
20"
Working Depth on Non-Passive Surfaces**
(e.g. Hard & Dry Heavy Soils, etc.)
7.5"
10.6"
16"
7.5"
10.6"
16"
7.5"
10.6"
16"
7.5"
10.6"
7.5"
10.6"
7.5"
10.6"
Weight (lbs.)
11,880
12,056
16,060
12,430
12,980
16,720
13,200
14,080
17,600
14,014
15,400
14,850
16,720
15,730
18,040
Weights are Less Pallets, Crates, PTO Shaft & Rollers.
(DT) Denotes Double Transmission
*This dimension represents Maximum Single Pass Working Depth, subject to moderate ground conditions, allowing Max. Plow Share & Skid penetration. **This dimension represents the distance from the Tip of the Teeth, to the bottom of the Skid Shoes – typically applicable to determining Max. Single Pass Milling Depth (on Asphalt, Chip Seal Roads & other Hard Surfaces).
'AA' SERIES FORESTRY TILLER SPECIFICATIONS
MODEL
AA1800DT
AA2000DT
AA2300DT
AA2500DT
AA2800DT
AA3000DT
L
N
M
L
N
M
L
N
M
L
N
L
N
L
N
Tractor Horsepower
200-450HP
220-450HP
320-450HP
220-450HP
240-450HP
340-450HP
240-450HP
280-450HP
360-450HP
280-450HP
320-450HP
300-450HP
340-450HP
320-450HP
360-450HP
Rotor Diameter
31.5"
36"
45.5"
31.5"
36"
45.5"
31.5"
36"
45.5"
31.5"
36"
31.5"
36"
31.5"
36"
Working Width
5'-9"
6'-7"
7'-5"
8'-3"
9'-1"
9'-11"
Overall Width
7'-3"
8'-1"
8'-11"
9'-9"
10'-7"
11'-5"
Quantity of Teeth
152
170
228
170
185
265
198
220
302
214
238
232
256
250
274
Side Drive Gears (Qty)
4
6
4
6
4
6
4
4
4
Working Depth on Passive Surfaces*
(e.g. Dirt, Gravel, Sod, etc.)
16"
20"
28"
16"
20"
28"
16"
20"
28"
16"
20"
16"
20"
16"
20"
Working Depth on Non-Passive Surfaces**
(e.g. Hard & Dry Heavy Soils, etc.)
7.5"
10.6"
16"
7.5"
10.6"
16"
7.5"
10.6"
16"
7.5"
10.6"
7.5"
10.6"
7.5"
10.6"
Weight (lbs.)
11,880
12,056
16,060
12,430
12,980
16,720
13,200
14,080
17,600
14,014
15,400
14,850
16,720
15,730
18,040
Weights are Less Pallets, Crates, PTO Shaft & Rollers.
(DT) Denotes Double Transmission
*This dimension represents Maximum Single Pass Working Depth, subject to moderate ground conditions, allowing Max. Plow Share & Skid penetration. **This dimension represents the distance from the Tip of the Teeth, to the bottom of the Skid Shoes – typically applicable to determining Max. Single Pass Milling Depth (on Asphalt, Chip Seal Roads & other Hard Surfaces).
Specifications & Designs Are Subject to Change Without Notice
