Selvatici Series E220.250 3-Point Spading Machines -- Iowa Farm Equipment

Selvatici Series E220.250
Tractor 3-Point Spaders, Spading Machines

Bullet Proof, Durable, Low Demand Machines Producing Unparalleled Results!

The Large E220-250 Series Spaders Have Multi-Speed Gearboxes, Suitability For 80 – 250HP Tractors, Working Widths Up To 13’ Wide, and Provide Highly Concentrated Penetrations Up to 20” Deep, With Single Pass Efficiency!

STANDARD FEATURES:

Heavy Duty, 540 or 1000RPM, Large Sump Multi-Speed Gearbox.
Slip Clutch Protected PTO Shaft.
Category 2, 3-Point Hitch with Clevis Style Hitch Pin Frames.
Multi-Speed, Large Sump Gearbox with Easy Shift External Lever For Accommodating a Broad Range of Soil Types & Activities!
Selvatici's Wear-Resistant Spader Blades Use 'Ultra-High Strength Steel, Alloyed With 30MnB5 Boron' To Endure Tough Ground & Rocks!
Multiple Holding Positions of Rear Gate, From Open to Closed:
- Works in Conjunction with Multi-Speed Gearbox, For Varied Soil Results, and Varied Soil Moisture.
Multi-Positioned, Anti-Clogging Frame Also Accommodates Varied Soil Moisture Conditions.
Greaseable Bearings with Metal Seals For Extended (50hour) Intervals.
Skid Shoes For Easy, Tool Free Working Depth Control.

E220.250 SERIES SPECIFICATIONS
MODEL	E2008	E2508	E2510	E3010	E3012	E3512	E3514	E4016
Working Width	79"	97"	97"	9'-10"	9'-10"	11'-6"	11'-6"	13'-2"
Overall Width	81"	99"	99"	10'-0"	10'-0"	11'-8"	11'-8"	13'-4"
Minimum HP	80HP	90HP	90HP	100HP	120HP	130HP	130HP	140HP
Maximum HP	250HP
Maximum Working Depth	20"
Number of Spades	8		10		12		14	16
Gearbox Speeds @540RPM	109, 120, 133, 147, 163, 180, 199, 221 & 245RPM’s
Gearbox Speeds @1000RPM	117, 131, 147, 164, 182, 202, 223 & 247RPM’s
Weight	5,060lbs.	5,414lbs.	5,766lbs.	6,160lbs.	6,490lbs.	7,260lbs.	7,568lbs.	8,404lbs.

E220.250 SERIES SPECIFICATIONS
MODEL	E2008	E2508	E2510	E3010	E3012	E3512	E3514	E4016
Working Width	79"	97"	97"	9'-10"	9'-10"	11'-6"	11'-6"	13'-2"
Overall Width	81"	99"	99"	10'-0"	10'-0"	11'-8"	11'-8"	13'-4"
Minimum HP	80HP	90HP	90HP	100HP	120HP	130HP	130HP	140HP
Maximum HP	250HP
Maximum Working Depth	20"
Number of Spades	8		10		12		14	16
Gearbox Speeds @540RPM	109, 120, 133, 147, 163, 180, 199, 221 & 245RPM’s
Gearbox Speeds @1000RPM	117, 131, 147, 164, 182, 202, 223 & 247RPM’s
Weight	5,060lbs.	5,414lbs.	5,766lbs.	6,160lbs.	6,490lbs.	7,260lbs.	7,568lbs.	8,404lbs.

Specifications & Designs Are Subject to Change Without Notice
