Selvatici Series 220.350 Tractor 3-Point Soil Spading Machines

Selvatici 220.350 Tractor PTO Spading Machine

The Series 220.350 Spading Machines are for very deep grounds, high power and output. The spade clearance, depending on the rished clods, can be selected in the large and unique range. The 220.350 Series is a maximum depth, high speed spading machine for high power tractors.

220.350 SERIES SOIL SPADER STANDARD FEATURES:

  • Lever-Shift 3 Speed Gearbox PdF 1000 = | 135 || 160 ||| 185.
  • 3-Point Hitch with Varying Distance Cat II.
  • Lubrication of Connecting Rods with Steel Seals.
  • Protected PTO Shaft with Clutch.
  • PdF Posterior Exit.
  • Hood Cover with Spikes.
  • Slides for Depth Adjustment.

Selvatici 220.350 Tractor Spading Machine

THE GEAR IS GIGANTIC (1036lbs.): The pinion shaft & the PTO are supported by 3 bearings. The gearbox has 3 speeds. Its configuration allows the transmission of motion with gears only in socket: others are free, resulting in maximum efficiency & less wear. The forced circulation is guaranteed by numerous channels formed by mergers. The oil flow per revolution is constant & determined by an internal turbine, therefore, immune from problems caused by filters, pipes, radiators or pumps.

Selvatici 220.350 Tractor 3 Point Spading Machine

Selvatici Spading Machine Standard Features:

  • Selvatici Spading Machines acheive land drainage and reduction of the risk of soil being washed down off slopes, since the cultivated soil does not rest on the hard layer. This avoids a typical negative characteristic of land worked using other tilling equipment.
  • Working of the soil is homogeneous throughout the width of the machine, turning the soil in a uniform manner so as to assist in ploughing in the fertilizer, manure or stubble.
  • The Selvatici Spading Machines yield tilled soil with a flat surface and clods that are regular in size, so that it is often possible to proceed with sowing or planting immediately. The spades enter the soil one at a time, allowing a minimum use of tractor power, and they last longer because they only work in descent.
  • The Selvatici Spading Machines are the only implement that doesn't form compact and tight soil beds where it passes. Consequently, the roots are not hindered from growing, nor is moisture hindered from getting to the roots. Priming in the slopes, it does not CAUSE the dangerous phenomena of soil erosion.
  • Selvatici Spading Machines reduce fuel consumption compared to conventional tilling processes like plowing, ripping and milling.
  • Selvatici Spading Machines are the only implement always resulting in the clod turning over and allows the soil to air quickly, eliminating noxious weeds with their roots.
  • Selvatici Spading Machines are the only implement requiring no tractive or braking effort from the tractor, meaning that it can also be used on steep grades without any inconvenience and in a safe manner.

Selvatici 220.350 Tractor 3-Point Spading Machine

Selvatici 220.350 Heavy Duty Spading Machine

220.350 SERIES SPECIFICATIONS
Model G2508 G2510 G3010 G3012 G3512 G3514 G4016 G4516
Working Width 97" 118" 138" 158" 177"
Minimum HP 120 HP 130 HP 140 HP 160 HP 180 HP 200 HP
Maximum HP 350 HP
Number of Spades 8 10 12 14 16
Weight 5,423 lbs. 5,798 lbs. 6,239 lbs. 6,570 lbs. 7,011 lbs. 7,341 lbs. 8,135 lbs. 8,642 lbs.
Specifications & Designs Are Subject to Change Without Notice
